Stainless Steels
FW 317
AWS: SFA 5.9 ER317
EN ISO CODE:
FW 317 is a solid wire for TIG welding, available in bright finish, gives smooth flow, stable arc and spatter free under optimum welding conditions. It gives radiographic quality welds. It is ideally suited for welding of stainless steels of similar composition and their equivalents. It has excellent resistance against Sulfuric, Sulfurous and phosphoric acids.
Approvals
CHEMICAL COMPOSITION OF ALL WELD METAL (%)
| Element | C | Mn | Si | S | P | Cr | Ni | Mo |
| Percent | 0.06 | 1.2 | 0.40 | 0.015 | 0.018 | 19.5 | 14.0 | 3.5 |
TYPICAL MECHANICAL PROPERTIES OF ALL WELD METAL
| UTS | Elongation |
| (MPa) | (L= 5d)% |
| 570 | 34.0 |
SHIELDING GAS
Argon
CURRENT CONDITIONS
DCEN
WELDING POSITIONS
H, F, VU, OH
PACKING
STANDARD SIZE: Diameter 1.6 mm, 2.0 mm, 2.4 mm & 3.2 mm in cut lengths of 1000 mm each.
QUANTITY 5 kgs wire put in an air-tight polythene bag and finally packed in a plastic container.
Identification – AWS code is punched on each wire.
