Medium and High Tensile Steel
TENSAL-MH
AWS: SFA 5.5 E9018-M
EN ISO CODE: 18275-B E 62 18-N3M1 A H5
Extra low hydrogen type electrodes depositing a high strength weld metal. Ideally suited for welding fine-grained steels, high strength steels, Q&T steels used in the fabrication of structures, bridges, penstocks and other components.
Approvals
CIB-MP
CE
CHEMICAL COMPOSITION OF ALL WELD METAL (%)
| Element | C | Mn | Si | Ni | Mo | S | P |
| Percent | 0.06 | 1.20 | 0.35 | 1.60 | 0.30 | 0.018 | 0.018 |
MECHANICAL PROPERTIES OF ALL WELD METAL
| UTS | YS | Elongation | CVN Impact Strength (J) |
| (MPa) | (MPa) | (L= 5d)% | at Minus 50°C |
| 644 | 554 | 26 | 50 |
CURRENT AND PACKING DATA: DC (+)
| Size (mm) | 6.3x450 | 5x450 | 4x450 | 3.15x350 | 2.5x350 |
| Current Range (Amps) | 280-350 | 200-250 | 140-190 | 100-140 | 80-100 |
| Qty. (Pcs./Carton) | 25 | 35 | 55 | 75 | 125 |
